How to install caster universal wheel correctly
1, Install 3 casters, including 1 universal wheel and 2 directional wheels
The installation combination of 1 universal wheel and 2 directional wheels is suitable for
short-distance handling of low center of gravity, medium and light equipment, with good directional
control and economy.
2, Install 4 casters, including 2 universal wheels and 2 directional wheels
The combination of two universal wheels and two directional wheels is a conventional assembly method.
There are two directional wheels in the front and two movable universal wheels close to the push
handrail in the rear. It is suitable for long-distance and long-distance transportation of heavy equipment,
which is economical and durable.
3, Install 4 casters, all of which are directional wheels
The 4 directional wheels are of rhombic layout design, which is suitable for long straight-line
transportation of heavy equipment and cannot be used on sloping working faces.
4, Install 4 casters, including 2 directional wheels and 2 universal belt brake wheels
Two universal belt brake wheels and two directional wheels are installed. There are two directional
wheels in the front and two universal belt brake wheels close to the push handrail in the rear. This
assembly is suitable for long and short distance and sloping roads.
5, Install 4 casters, all universal wheels
The installation method of 4 universal wheels is suitable for short-distance handling of heavy
equipment. It has excellent directionality and is often used for turnover work vehicles in factory
workshops.
6, Install 6 casters, including 4 universal wheels and 2 directional wheels
4 universal wheels and 2 directional wheels are suitable for long-distance handling of heavy equipment
and household countertops. They have good handling and are used for horizontal contact surfaces.
Industrial Swivel Casters Parameter
| Wheel material | Nylon6 |
| Load Capacity | 700KG |
| Wheel Diameter | 75mm |
| Color | white |
| Tread Width | 50mm |
| Load Height | 108MM |
Industrial Swivel Casters Describe
Industrial Swivel Casters Size
Industrial Swivel Casters Material
| | Name | Material | Treatment |
| 1 | Caster Seat | Cold-rolled carbon steel | Black Coated/Zn Galvanized |
| 2 | Body | Aluminum alloy | Ivory/Powder Coated |
| 3 | Ball | Bearing Steel | Ni-Cr |
| 4 | Brake | Steel 45 | Zn Galvanized |
| 5 | Pin | Steel 10 | Zn Galvanized |
| 6 | Wheel | PA6 | Black |
Industrial Swivel Casters Scope of application
Application.
Communication equipment, semiconductor manufacturing equipment, experimental equipment,
medical equipment, printing machines, all kinds of Press, all kinds of special machinery, all kinds
of variable production equipment, dust-free room equipment, aluminum frame, equipment, etc.
About us.
KTC (Bejing Korea Technology Caster Co., Ltd.) was founded in 2007. KTC is a modern
company specialzingin the production of multi function &high quality CASTER and
KT FOOT based on best design and design technology.
KTC.
The company is headquartered in Niulanshan Industrial Zone,Shunyi District, Beijing. KTC
adopts international advanced production testing equipments, professional intelligent
production management system and professional design flow. Now the company produces
multi function & high quality production, such as KT CASTER and KT FOOT, among which
high quality of height adjusting CASTER,shockproof type CASTER, high quality of height
adjusting CASTER, shockproof type CASTER,high load CASTER and level adjusting FOOT
are widely used in the world's advanced automation equipment and semiconductor e
quipment industry.
In order to manufacture the world's highest level of products,KTC use the best processing
technology and equipment. And KTC continuously launches world top level of new products.
KTC's s also has set up a branch in Korea, so it is favored by theusers of various fields around
the world.
